BD Locking Ring Type Tubing Elevator
BD Locking ring type tubing elevators are conventional tools to handle the tubing in the oil and gas drilling operation. BD Locking ring type tubing elevators series are made from high quality alloy steel, heat-treated and NDT. And can handle tubing range from 1.9in to 4 1/2EU O.D. Rating loads of Tubing Elevators are 40t (360kN), 65t (585kN), 75t (675kN). All the technical data and property of the elevator conform to API Spec 8C and SY/T 5035.
1.Single-ended oil pipe elevators
Type
Bore Dia
Rating Load
External Dia of pipes
mm
KN（tons）
in
mm
BD 50-££
50.19
355（40）
445（50）
665（75）
1.9
48.3
BD 56-££
55.96
1.9 EU
53.2
BD 63-££
62.27
2 3/8
60.3
BD 69-££
68.66
2 3/8 EU
65.9
BD 75-££
74.98
2 7/8
73
BD 82-££
81.36
2 7/8 EU
78.6
BD 91-££
90.88
3 1/2
88.9
BD 98-££
98.02
3 1/2 EU
95.3
BD 104-££
103.58
4
101.6
BD 111-££
110.72
4 EU
108
BD 117-££
116.95
4 1/2
114.3
BD 123-££
123.42
4 1/2 EU
120.7
2.Double-ended oil pipe elevators
Type
Bore Dia
Rating Load
External Dia of pipes
TopBore
Bottom Bore
KN
in
mm
BD 50×56-££
55.96
50.19
355（40）
455（50）
655（75）
1.9 EU
48.3×53.2
BD 63×69-££
68.66
62.27
2 3/8 EU
60.3×65.9
BD 75×82-££
81.36
74.98
2 7/8 EU
73×78.6
BD 91×98-££
98.02
90.88
3 1/2 EU
88.9×95.3
BD 104×111-££
110.72
103.58
4 EU
101.6×108
BD 117×123-££
123.42
116.95
4 1/2 EU
114.3×120.7
