Type C/CHD Pneumatic spiders

Type C/CHD Pneumatic spiders are utilized to handle drill pipe and tubing in oil well repairing. This type of spider can accommodate pipe from 1.315 to 5 1/2 inch, the rated capacity of type C Spider is 80 tons, and the rated capacity of type CHD Spider is 120 tons.

Slip Body Size(in)	Model				Cylinder Work Pressure
	C/80T		CHD/120T		Cylinder Work Pressure
	mm	in	mm	in	MPa	psi
2 1/16	33.4	1.315	33.4	1.315	0.6-0.9	87-130
	42.2	1.66	42.2	1.66
	48.3	1.9	48.3	1.9
	52.4	2 1/16	52.4	2 1/16
3 1/2	60.3	2 3/8	60.3	2 3/8
	73	2 7/8	73	2 7/8
	88.9	3 1/2	88.9	3 1/2
4 1/2	88.9	3 1/2	88.9	3 1/2
	101.6	4	101.6	4
	114.3	4 1/2	114.3	4 1/2
4 3/4	120.65	4 3/4	120.65	4 3/4
5	127	5	127	5
5 1/2	139.7	5 1/2	139.7	5 1/2
