SJ series auxiliary elevator(Single Joint Elevator)
SJ series auxiliary elevator is mainly used as a tool in handling single casing or tubing in oil and natural gas drilling and cementing operation. The products shall be designed and manufactured according to the requirements in API Spec 8C Specification for Drilling and Production Hoisting Equipment .
|
型号Model |
卡持管径Size |
额定载荷Rated Cap（KN） |
|
|
SJ |
in |
mm |
45 |
|
2 3/8 |
60.3 |
||
|
2 7/8 |
73 |
||
|
3 1/2 |
88.9 |
||
|
4 |
101.6 |
||
|
4 1/2 |
114.3 |
||
|
4 3/ 4 |
120.65 |
||
|
5 |
127 |
||
|
5 1/2 |
139.7 |
||
|
5 3/4 |
146.05 |
||
|
6 |
152.4 |
||
|
6 5/8 |
168.28 |
||
|
7 |
177.8 |
||
|
7 5/8 |
193.68 |
||
|
7 3/4 |
196.85 |
||
|
8 5/8 |
219.8 |
||
|
9 5/8 |
244.48 |
||
|
9 7/8 |
250.83 |
||
|
10 3/4 |
273.05 |
||
|
11 3/4 |
298.45 |
||
|
12 7/8 |
327.03 |
||
|
13 3/8 |
339.73 |
||
|
13 5/8 |
346.08 |
||
|
14 |
355.6 |
||
|
16 |
406.4 |
||
|
18 5/8 |
473.08 |
||
|
20 |
508 |
||
|
21 1/2 |
546.1 |
60 |
|
|
22 |
558.8 |
||
|
24 |
609.6 |
||
|
24 1/2 |
622.3 |
||
|
26 |
660.4 |
||
|
27 |
685.8 |
||
|
28 |
711.2 |
||
|
30 |
762 |
||
|
32 |
812.8 |
||
|
36 |
914.4 |
||
|
*非标尺寸请联系厂家定制加工 |
|||
