Type E Pneumatic spiders
Type E Pneumatic spiders are utilized to handle drill pipe and tubing in oil well repairing. This type of spider can accommodate pipe from 23/8 to 75/8 inch, the rated capacity is 175 tons.
|
Slip Body Size(in) |
Model |
Cylinder Work Pressure |
Rated Load |
||
|
E/175 Tons |
|||||
|
Pipe Size |
|||||
|
in |
mm |
Mpa |
Psi |
Ton |
|
|
3 1/2 |
2 3/8 |
60.3 |
0.6-0.9 |
87-130 |
175 |
|
2 7/8 |
73 |
||||
|
3 1/2 |
88.9 |
||||
|
5 1/2 |
4 |
101.6 |
|||
|
4 1/2 |
114.3 |
||||
|
5 |
127 |
||||
|
5 1/2 |
139.7 |
||||
|
7 |
6 1/4 |
158.8 |
|||
|
6 5/8 |
168.3 |
||||
|
7 |
177.8 |
||||
|
7 5/8 |
7 5/8 |
193.7 |
|||
